磁珠温馨提示：如果您需要详细参数描述，请点击下方“免费索取”按钮向客服人员索取PDF文件。
免费索取
|
Part Number |
Reverse Stand-off |
Reverse Breakdown |
Test Current IT (mA) |
Clamping Voltage
@Max Ipp |
Revrse Leakage Current Ir@Vrwm (µA) |
Maximm Peak Pulse Surge Current Ipp(A) |
||
|
Uni-directional |
Bi-directional |
Min. |
Max. |
|||||
|
SMC5K10A |
|
10 |
11.1 |
12.3 |
1 |
17.0 |
10 |
294 |
|
SMC5K12A |
|
12 |
13.3 |
14.7 |
1 |
19.9 |
5 |
251 |
|
SMC5K13A |
|
13 |
14.4 |
15.9 |
1 |
21.5 |
2 |
233 |
|
SMC5K14A |
|
14 |
15.6 |
17.2 |
1 |
23.2 |
2 |
216 |
|
SMC5K15A |
|
15 |
16.7 |
18.5 |
1 |
24.4 |
2 |
205 |
|
SMC5K16A |
|
16 |
17.8 |
19.7 |
1 |
26 |
2 |
192 |
|
SMC5K17A |
|
17 |
18.9 |
20.9 |
1 |
27.6 |
2 |
181 |
|
SMC5K18A |
|
18 |
20.0 |
22.1 |
1 |
29.2 |
2 |
171 |
|
SMC5K20A |
|
20 |
22.2 |
24.5 |
1 |
32.4 |
2 |
154 |
|
SMC5K22A |
|
22 |
24.4 |
26.9 |
1 |
35.5 |
2 |
141 |
|
SMC5K24A |
|
24 |
26.7 |
29.5 |
1 |
38.9 |
1 |
129 |
|
SMC5K26A |
|
26 |
28.9 |
31.9 |
1 |
42.1 |
1 |
119 |
|
SMC5K28A |
|
28 |
31.1 |
34.4 |
1 |
45.4 |
1 |
110 |
|
SMC5K30A |
|
30 |
33.3 |
36.8 |
1 |
48.4 |
1 |
103 |
|
SMC5K33A |
|
33 |
36.7 |
40.6 |
1 |
53.3 |
1 |
93.8 |
|
SMC5K36A |
|
36 |
40.0 |
44.2 |
1 |
58.1 |
1 |
86.1 |
|
SMC5K40A |
|
40 |
44.4 |
49.1 |
1 |
64.5 |
1 |
77.5 |
|
SMC5K43A |
|
43 |
47.8 |
52.8 |
1 |
69.4 |
1 |
72 |
|
SMC5K45A |
|
45 |
50.0 |
55.3 |
1 |
72.7 |
1 |
68.8 |
|
SMC5K48A |
|
48 |
53.3 |
58.9 |
1 |
77.4 |
1 |
64.6 |
|
SMC5K51A |
|
51 |
56.7 |
62.7 |
1 |
82.4 |
1 |
60.7 |
|
SMC5K54A |
|
54 |
60.0 |
66.3 |
1 |
87.1 |
1 |
57.4 |
|
SMC5K58A |
|
58 |
64.4 |
71.2 |
1 |
93.6 |
1 |
53.4 |
|
SMC5K60A |
|
60 |
66.7 |
73.7 |
1 |
96.8 |
1 |
51.7 |
|
SMC5K64A |
|
64 |
71.1 |
78.6 |
1 |
103 |
1 |
48.5 |
|
SMC5K70A |
|
70 |
77.8 |
86.0 |
1 |
113 |
1 |
44.2 |
|
SMC5K75A |
|
75 |
83.3 |
92.1 |
1 |
121 |
1 |
41.3 |
|
SMC5K78A |
|
78 |
86.7 |
95.8 |
1 |
126 |
1 |
39.7 |
|
SMC5K85A |
|
85 |
94.4 |
104 |
1 |
137 |
1 |
36.5 |
